5 - 7 Ton Excavator Class Skid Steer Coupler Adapter

Cat® Skid Steer Adapters allow connecting to certain recommended Skid Steer Interface Type attachments. Adapters are available for both Mini Hydraulic Excavators and Compact Wheel Loaders, to allow sharing of tools across different machine families and reducing job site storage space storage by eliminating machine specific tools.

Documents




    Compare




    Application

    Designed to allow the use of approved Skid Steer Loader attachments on Mini Hydraulic Excavators.

    Bolt-On Hose Guide

    Provided to help guide hydraulic hoses when using approved hydro-mechanical attachments with the coupler. Can be mounted on either side of the adapter to accommodate your specific tools and needs.

    Cross Tube Reinforced Design

    Reinforced cross tube design provides the needed stability to operate a wide range of approved attachments.

    Open Frame

    The open frame design provides visibility to attachments to aid in safer and easier coupling operation of attachments.

    Integrated Stand

    When not in use, the integrated stand keeps the adapter in an upright position. This helps maintain keeping it in the correct position for attachment to your machine either by pinning on, or by quick coupler.

    Pins Included

    All Mini Hydraulic Excavator to Skid Steer Loader adapters come complete with a set of pins.

    Compatible Attachments

    5 Ton version approved attachments: General Purpose Buckets, Bale Spears, and Class II Forks.

    Weight119kg262.3lb
    Width1125mm44.3in
    Overall Length476mm18.7in
    Overall Height557mm21.9in
    Pin Diameter45mm1.8in
    Excavator Class5 Ton - 7 Ton
    Interface TypePin On
    Coupler TypeAdapts to Skid Steer Coupler
    Required HydraulicsNone
